JDA146 mini DisplayPort? to Dual DisplayPort? Adapter
JDA146 mini DisplayPort? to Dual DisplayPort? Adapter
- Supports resolutions up to 4k @ 30Hz
- Extends single mDP to dual display
- Enables 2 monitors to work simultaneously with extended mode, expansion mode or mirror mode
- No drivers needed, simply plug & play
- Perfect for Microsoft© Surface Pro? and Lenovo© ThinkPad?
The JDA146 mini DisplayPort? to Dual DisplayPort? Adapter allows you to connect up to two DisplayPort? monitors from a single Mini DisplayPort? output. The JDA146 utilizes multi-stream transport (MST) protocol, supporting up to 2 displays independently at up to 4k @ 30Hz each with DP 1.2.
Hardware | |
Connector Type | Passive |
Interface | |
Host Interface | Mini-DisplayPort (20 pin) Male |
Video Interface | DisplayPort (20 pin) Female |
Power | |
Power Source | USB-Powered |
| Physical Specifications | |
Housing Material | Plastic |
Dimensions | Main body: 7.6 (W) x 3.3 (H) x 1.6 (D) cm Cable length: 5.9 in./15 cm |
Weight | Approximately 0.0425 kg |
SYSTEM REQUIREMENTS
- The graphics card for DisplayPort 1.2 with MST+HBR2
- Available DisplayPort alt mode over USB type-C port
- Mac OS X does not support MST + HBR2
- Requires an external USB Power source (USB cable included)
- Extended dual HDMI supported by Windows only (Microsoft Surface Pro2, Pro3, Pro4, Book supports MST+HBR2)
